The SFP 'ISO-LAB' series pressure vessels have been developed by to offer a range of small, medium and large high pressure vessels for general purpose applications. Pressure vessels are manufactured in a variety of construction styles to suit pressures and applications. Vessel closures include continuously threaded and quick release (1/8th turn). Dependent on requirements and operating pressures these vessels may also be supplied with a a variety of lower closures including quick release, continuously threaded, taper plug and blind end construction.

ISO-LAB vessels are suitable for operation with inert liquids and gases with variants for a variety of corrosive fluids. Typical operating temperatures are from 10°C to 80°C with extended temperature ranges also available. Options on temperature include heating/cooling jackets and furnace modules.

In addition to standard high pressure entries, generally at least one at each end of the vessel, vessels may also be supplied with a range of SFP's telemetry lead through's (signal wire, electrodes, thermocouples etc.) or to suit third party instruments.

To assist closure operation vessels having a bore in excess of 75mm (3") may also be supplied with hydro-pneumatic, or hydraulic closure lift. Mounting frames and other ancillaries are also available.

Most vessels may be offered with different internal lengths. It is unusual to have a length to bore ratio less than 1:1 while up to 10:1 is not unusual. Contact us to discuss your High Pressure Vessels requirements

Monoobloc vessel, continuously threaded closures both ends. Generally used for medium and low pressures and where vessels are not opened frequently. Monoobloc vessel, blind end, quick release, interrupted thread top closures. Generally used for medium and low pressures and where vessels are frequently opened.

See also: Small Large Ø3 - 75mm Ø.0.1 - 3" Ø200 to 1000+mm Ø8" to 40"+ More details More details

Duplex (compound barrel) vessel with taper plug liner and quick release, interrupted thread top closures. Generally used for medium and high pressures, where vessels are frequently opened. Mantle Barrel vessel with quick release, interrupted thread top closures. Generally used for medium and high pressures, where vessels are frequently opened. Especially suitable for high numbers of pressure cycles.

Contact us to discuss your High Pressure Vessels requirements
